| VARIANT | DETAILS | ||
|---|---|---|---|
| Engine | ISB-220-40 in-inline, Six-Cylinder, Water Cooling, Four Stroke, Direct Injection, Turbo Charging, Inter Cooling Diesel Engine | ||
| Displacement | 5,900 cc | ||
| Power Output | 220 HP / 2,500 RPM | ||
| Torque | 800 NM @ 1,500 rpm | ||
| Transmission | 8-speed manual | ||
| Payload Capacity | 15,155 kg | ||
| Crane Specification | |||
| Max Lifting Capacity | 5,000 kg | ||
| Max Lifting Moment | 125 KN-m | ||
| Max Lifting Height | 11m | ||
| Wheels & Tires | 6+1 / 11R22.5 | ||
| Brakes | Dual Circuit Pneumatic Brake | ||
| Parking Brakes | Energy Accumulating Spring Air Cut-off Brake | ||
| Auxiliary Brakes | Engine Exhaust Brake | ||
| Emission Norms | Euro IV | ||
| Fuel Type | Diesel | ||
| Cab type | Day Cab | ||
| Steering | Power Steering, Tiltable Steering, Steering Adjustable | ||
| Other Features | Drive Information Display, ABS (Potentially, information not explicity confirmed) | ||
